5008677BXW Genuine Paccar PS-60 Low Air Pressure Sensor Transductor
Call us at: +1 (252) 220-8829
PRODUCT DESCRIPTION
Description: PS-60 Low Air Pressure Sensor Transductor For Kenworth, Peterbilt
Condition: New
Brand: Paccar
Part Number: 5008677BXW
Other OEM Part Numbers That Will Work: 704572AT
Connector Type - Metri-Pack 150 Series 3-Way Sealed Connector (Male)
Pneumatic Connection - Ø 3/8 IN Stem
Operating Voltage Range - 4.75 VDC - 5.25 VDC
Current (Nominal) - 8.0 mA
Operating Pressure Range - 0-150 PSI
Accuracy - ± 3.0% of the Full Scale Output (5 VDC)
Maximum Operating Temperature - 257 °F (125 °C)
Minimum Operating Temperature - -40 °F (-40 °C)
Cautionary Note(s) - Mates with 3/8" Weatherhead QCAB / Parker Prestomatic Fittings
